The Coral Doser is a new peristaltic dosing pump from HM Electronics which is a new product category for the Taiwanese company. You may not be entirely familiar with HM ELECTRONICS but they’ve developed many innovative LED aquarium lights like the Gesture controlled wing led, the Cetus 2 Spotlights, and OEM products that have been rebranded by companies all over the world.
With their new peristaltic pump HM Electronics (HME) is applying their creativity in design and engineering to the all important need for dosing in our reef and freshwater planted aquariums. The stepper motor driven Coral Doser has software that enables ‘micro stepping’ of the super accurate motor drive to deliver a ridiculous 1/80,000th of a rotation for infinitesimally small doses.
Certainly this level of precision is beyond overkill for aquarium applications but hopefully we can take this to mean that all other aspects of the HME Coral Doser will hyper accurate as well. The Coral Doser can be used for typical dosing of chemical aquarium solutions, it is programmed with either an iOS or Android app, and built-in ports can receive one or two optical water level sensors to use as an Auto Top Off device.
The team at HM Electronics has worked hard to make the Coral Doser a very robust aquarium device with lots of water resistant features and moisture barriers so it can be operated in very humid environments. HM Electronics has already proven their engineering chops with a myriad of lighting products so we have very high expectations for their new Coral Doser and look forward to trying some out for a range of applications.
- Precision DC Stepper Motor with microstepping controlled technology reach accuracy of ± 0.05ml (<5ml) and ± 1% (>5ml) or 0.4% (>5ml) average deviation.
Long Term Accuracy and Stability
- Stainless ball bearing roller and stepper motor can stay exactly the same accuracy after dosing 60000ml.
Wide Range Dosing Capability
- Automatic speedy water change or add additives continuously and slowly at dose range 0.1~105ml/min.
Cost Saving for Tube
- Extremely low friction design ensure the life span of the tube up to 1 year (200ml/day).
- Whisper quiet operation for full rate range.
- Pairing and grouping multi-doser automatically.
- Freely adding multiple dosing time-period with different dosage.
- Automatic scheduling
- Preventing chemical interaction
- History Record for 28 days.
- Stirring function
- ATO Function
- Automatic water change function.
- Automatic notify when the additive is about to run out.
- Working with HME Stirrer and stirring automatically before dosing.
- No need additional power adapter.
- 3 stirring rates can be selected.
Optional Level Sensor
- Coral Doser can connect with two water level sensors.
- Two separate sensors, double reliability.
- Top up slowly and accurately.
- It is very important to maintain water quality.
Easy to Maintain
- The tube can be easily replaced without any tools.
Model: Coral Doser P2
Adapter: 12V/2.5A X1
Dimensions: 2.8" H x 2.8" W x 2.6"L (2x Coral Doser P1)
Dose Rate: 0.1~105ml/min
Daily Dosage: 0.1~2000ml/day
Input voltage: 100~240VAC,50/60Hz
Tubing connection: 4mmID,6mmOD
